8

Englis

h

Left view

Information on USB 3.0

Compatible with USB 3.0 and earlier USB devices.

For optimal performance, use USB 3.0-certified devices.

Defined by the USB 3.0 specification (SuperSpeed USB).

#

Icon

Item

Description

1

DC-in jack

Connects to an AC adapter.

2

Ethernet (RJ-45)
port

Connects to an Ethernet 10/100/1000-
based network.

3

External display
(VGA) port

Connects to a display device
(e.g., external monitor, LCD projector).

4

HDMI port

Supports high definition digital video
connections.

5

USB port

Connects to USB devices.
If a port is black it is USB 2.0 compatible, if
it is blue it is also USB 3.0 compatible (see
below).

6

Microphone jack

Accepts inputs from external microphones.

Headphones/
speaker/line-out
jack

Connects to audio line-out devices
(e.g., speakers, headphones).

2

6

1

3

5

4
