10
English
Base view
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery lock Locks the battery in position.
3 Memory compartment Houses the computer's main memory.
4 Hard disk bay Houses the computer's hard disk
(secured with screws).
5 Ventilation slots and
cooling fan Enable the computer to stay cool, even
after prolonged use.
Note: Do not cover or obstruct the
opening of the fan.
6 Battery release latch Releases the battery for removal.
