Acer TravelMate 3210 - Manual (Page 12)

3
English
Left view
7 Battery indicator Lights when the battery is being charged.
# Icon Item Description
1 External display
port Connects to a display device (e.g.,
external monitor, LCD projector).
2 S-video out port Connects to a television or display
device with S-video input. (on
selected models)
3 Network jack
(RJ-45) Connects to an Ethernet 10/100/
1000-based network (depends on
model).
4 Modem jack
(RJ-11) Connects to a phone line.
5 Two USB 2.0 ports Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
6 IEEE 1394 port Connects to IEEE 1394 devices.
(on selected models)
7 PC Card slot Accepts one Type II PC Card.
8 5-in-1 card reader Accepts an MS, MS PRO, MMC, SD,
xD-Picture card
(on selected models).
Note: Only one card can operate at
any given time.
9 Infrared port Interfaces with infrared devices (e.g.,
infrared printer and IR-aware
computer) (on selected models).
10 PC Card slot eject
button Ejects the PC Card from the slot.
# Icon Item Description
