C2G 40444 4 x 2 HDMI Matrix Switch User Manual

Page 6

Operating the Matrix Switch via RS-232 control

Transmission Format:

Baud Rate:

57600 BPS

Data Byte:

8 bits

Parity:

None

Stop Bit:

Flow control: None

Modem Cable Pinouts:

Switcher End

Controller End

Definition

1 NC

2 TxD

2 RxD

3 RxD

3 TxD

4 NC

5 GND

6 NC

7 NC

8 NC

9 NC

Command Code

Description

0x01

TV 1 Output Port On

0x02

TV 2 Output Port On

0x05

CH 1 Input Port On

0x06

CH 2 Input Port On

0x07

CH 3 Input Port On

0x08

CH 4 Input Port On

0x09

TV Output Power On/Off

Using Optional Infrared (IR) Extender Jack

The IR extender jack is for situations requiring the Matrix Switch to be mounted in a location
where direct line-of-sight is not available. If you have purchased a standard IR extension module,
connect it to the Extend IR jack of the unit and position the module in a manner that allows the
furnished remote to be pointed at it without any obstructions between the remote and the IR
extension module. The cable length will vary according to the manufacturer of the IR extension
module.

Operation using the extended IR module accessory is the same as with the standard IR remote
capability.
