1
Features:
• Plug ‘n’ Play: No software required
• Full Channel Selection for CATV up to channel 125
• 4 output resolutions, 1024X768, 800X600, 640X480, 852X480 (Mac)
• Stylish Design, can place upright (stand included) or horizontal
• Full-function remote control
• Front panel AV and S-Video inputs; Rear panel VGA in/out and 3.5mm audio in/out
• Adjustable TV function: brightness, hue, color, etc.
• Auto-Scan channel programming
• MTS Stereo for a true theater like experience
Connecting the Converter:
Front Panel
POWER
Switches the unit to by-pass
when in the OFF state
IR Receiver: Receives IR
signals from the remote
control
Audio Input
Video Input
S-Video Input
INPUT
Input selection, this is repeated
TVÆ CVBS Æ S-Video Æ PC
CH Select
CH+: Channel up
CH-: Channel Down
Volume Level
VOL+: Volume up
VOL-: Volume Down
