C2G 40972 Multi-Function Converter w_CATV Tuner & PIP - Manual (Page 13)

10
Troubleshooting:
Specifications:
CATV/TV Input 75 Ohm “F” type female connector
Video Input Composite Video, S-Video
Composite Video 75Ohm, 1V p-p via RCA type connector
S-Video 75Ohm, 1V p-p via 4-Pin mini-DIN
Audio Input (Signal Source) Stereo Audio via 2 RCA type connectors
Audio Input (PC) Stereo Audio via 3.5mm stereo connector
VGA In HD-15 Female
Power-AC/DC adaptor 12 V DC 500mA (UL, CE)
VGA Output HD-15 Female
Video Output (only Valid on TV Mode) 75Ohm, 1V p-p via RCA type connector
Audio Output Stereo Audio via 3.5mm stereo connector
Regulatory specification:
Complies with requirements of:
FCC 15.225
FCC Part 15-Class B
ICES-003
CE
Replaceable Parts
Part Number: 98000- AC/DC adapter
98023- Remote control
Problem Solution
No picture 1. Compare all connections to the appropriate
illustrations to verify correct connectivity.
2. Make sure the power adapter is connected to the
electrical supply and the converter.
3. Make sure that the selected mode is the same as the
input signal, and then perform Auto Scan.
No sound 1. Compare all connections to the appropriate illustrations
to verify correct connectivity.
No response while using the
remote control 1. Make sure that you are pointing to the IR sensor
window within 20ft. and within +/- 15 degrees of the
unit.
2. Check batteries and replace with new ones if
necessary.
In the event of a lost or
damage part, the following
replaceable accessories are
available. Please call
877-AV-EXPERT for order
information.
