Specifications – C2G 39960 4 Port VGA over UTP Extender- Base Unit User Manual
Page 4
Specifications
Function 39960
VGA In Connector
HD-15 Female x 1
VGA Out Connector
HD-15 Female x 1
RJ-45 Connector
4
Max. Resolution
2048x1536
60Hz
Cable Distance (Max.)
300 meters/1000 feet
Power Adapter (Min.)
DC 12V 600mA
Housing Aluminum
Weight (lbs)
.55
Dimensions (LxWxH)
inches
5x3.25x1.25
Distances and Resolutions for CAT5/5E and CAT6
cables
50M 2048x1536
100M 1280x1024
180M 1024x768
200M 800x600
CAT5/5E
300M 640x480
30M 1920x1440
50M 1280x1024
CAT6*
100M 800x600
* The optimizations provided by the extender product to compensate for skew in Cat5/5e cables
does not apply equally to Cat6. This is the reason for the reduced performance on Cat6 and why
Cat5/5e is recommended.
