AVSL 154.290 DLB50 User Manual

Page 7

154.290UK User Manual

Specifications

Power supply

90-270Vac, 50/60Hz (IEC)

Fuse

F1AL

Power consumption

18W

Housing material

Aluminium

Housing colour

Black

Beam angle

40°

LED type

10mmØ high output

LED power

75mW

LED lifespan

50,000 hours

Total luminous flux

955lm

LED quantity

160 (64 red, 48 green, 48 blue)

DMX channels

2, 3, 4, 7, 14 or 26

Projection distance

Luminous efficacy

53lm/W

DMX connection

3-pin XLR (in/out)

Operating temperature range

-20 to 45°C

Operating humidity range

0 - 90%

Internal Programmes

Strobe, sound & 13 x auto

Dimensions

540 x 67 x 65mm

Weight

1.3kg

Troubleshooting

No power (mains)

Check mains voltage is correct and outlet is switched on
Check IEC lead and fuse (if fuse continually blows, refer to your dealer)

No light output

Check control panel mode settings (internal program, slave, DMX etc.)
Check DMX settings from controller (dimmer levels, blackout etc.)

Unresponsive to DMX

Check DMX connection and leads
Check that DMX mode is enabled (set “Addr” on control panel)

DMX control not working
as expected

Check DMX mode in the menu settings
Check DMX start address

Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as Electrical or

Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life.
The goods must be disposed of according to your local council guidelines.

Errors and omissions excepted.
