11. CHANNEL 3 LINE INPUT
To be connected via a 6.3mm stereo jack plug.
12. CHANNEL 4 MIC INPUT
To be connected via a 6.3mm stereo jack plug.
13. CHANNEL 4 LINE INPUT
To be connected via a 6.3mm stereo jack plug.
14. MAIN OUTPUT
The final confirmed sound can be sent to the main amplifier via a 6.3mm stereo jack.
15. PRE OUT
To listen to the audio at a point before the master volume takes effect.
16. AUX OUT
This output 6.3mm stereo output jack is used to send line level signals
to external units.
17. PHONES
Headphone socket to monitor the output.
18 & 20. REPEAT/DELAY
These control the amount of effect that is added to the selected channel. To add the
effect turn the EFF (7) control clockwise.
19. LED MONITOR
Twin 6 segment LED ladders show the signal of the master output.
21. SUB-BASS FREQ CUT
A tone control to eliminate sub-bass frequencies.
22. SUB-BASS LEVEL
A volume control to allow a specific level of sub-bass to the output.
23. AUX VOL
A volume control for the AUX output (16).
