AVSL 153.300 SBF15 User Manual
Page 3
153.300UK User Manual
Setting up
If the SBF15 is to be mounted at height, use the integral bracket and fix a safety wire to the eyebolt (7)
The SBF15 can be free-standing on the floor or stable surface using the dual bracket as a bipod stand.
Position the SBF15 so that the front aperture is facing the area to be lighted.
Be careful not to aim the LEDs directly into eyes, as this can cause damage, especially at close range.
Experiment with positioning to get the best coverage – the SBF15 provides wide angle light dispersion.
Connect mains using an appropriate IEC lead to the mains inlet (8)
For DMX operation, connect DMX from a controller or preceding fixture to the DMX in connector (1).
Connect additional fixtures further along in the DMX chain from the DMX out connector (3).
Ensure that good quality DMX leads with 3-pin XLR connectors are used.
Operation
The SBF15 has 3 high output white LED strips, which can produce one of 4 different effects.
1. Chase 1-2-3
Sequence of each LED left to right with variable speed
2. Strobe effect
Short duration flashes
3. Blinder effect
Pulses with slow fade-out to simulate pyrotechnics or silhouette blinders
4. Flood light
Dimmable constant wash of white light
The SBF15 can be operated via internal programs or from a DMX signal (4ch) using the control panel.
Press the FUNC button and navigate the menus using UP, DOWN and ENTER buttons as shown below.
FUNC
Mode
Press ENTER for setting (press FUNC to exit)
DMX start address
to
Auto 1-2-3 chase
=
fast…
= slow
Sound activated modes
= 4 fast strobes triggered by a beat
= 1 blinder pulse triggered by a beat
Flood effect
=
10%…
= 100%
For more detailed control as part of a larger lighting system, DMX 512 control can be used.
If the start address is set to
,
then the following functions will apply.
DMX channel Function
Value
Dimmer LED 1
000 – 255: 0% to 100% (overrides preset programs)
Dimmer LED 2
Dimmer LED 3
Preset programs
000 - 100 Auto 1-2-3 chase: fast to slow
101 - 134 Master dimmer: 0% to 100%
135 - 167 Sound activated blinder pulse
168 - 200 Sound activated strobe chase 1-2-3
201 - 249 Strobe: slow to fast
250 - 255 Flood 100%
For all other address settings, each DMX channel is shifted up relative to the start address.
Note:
means that there is no DMX signal is present.
