154.015UK User Manual
Introduction
Thank you for choosing the QTX VL-65 5-colour LED PAR light as part of your effect lighting
rig. Please read these instructions in full to gain the best results from this item and avoid
damage through misuse.
Unpacking
Your VL-65 should reach you in good condition,supplied with appropriate mains lead(s) and
mounting bracket. If there is any damage or items missing from the packaging, contact your
dealer immediately.
Warning
To prevent risk of fire or electric shock, do not expose any components to rain or moisture.
If liquids are spilled on the housing, disconnect mains and allow unit to dry out & have
checked by qualified personnel before further use. Avoid any impact or extreme pressure to
the housing.
No user serviceable parts inside – Do not open the case – refer all servicing to qualified
service personnel.
Safety
 Check for correct voltage and condition of IEC lead before connecting to power outlet
 Ensure mains outlet has enough current rating to power all fixtures when connected by
daisy chain
 Ensure DMX leads are good condition with no short connections or damaged plugs
Placement
 Mount the unit to a lighting stand or ceiling using the adjustable bracket included
 If the unit is mounted at height, a drop cable should be attached for safety
 If free-standing, ensure that the unit is sited on a stable, non-slip surface.
 Ensure adequate access to controls and connections
Cleaning
 Use a soft dry or slightly damp to clean the cabinet. Do not use strong solvents for
cleaning the unit
Setting up
Install the VL-65 by the mounting bracket, which can also be configured as a floor stand.
Experiment with positioning and distance to get the best coverage for the area to be lighted.
For DMX or master/slave control, link DMX out to in with XLR leads.
Connect mains using the appropriate IEC lead to the mains inlet.
(can be ‘daisy chain’ connected on to further units)
