User Manual – PB-1 Foldable PAR BAR 151.559UK
4
Do not shake the device and avoid excessive force when installing or
operating
Do not use the device during thunderstorms and please disconnect the
power.
Do not use solvents or aggressive detergent to clean the device. Use a
soft and clean cloth.
Do not modify the device or the connected power cord without
authorization.
4. Connect with power supply:
Use the power supply provided to connect to the main power supply.
5. General maintenance :
To maintain optimum performance and minimize wear unplug fixture from
mains before conducting maintenance. Use a vacuum or air compressor and
a soft brush to remove dust collected on external vents and internal
components. Cleaning frequently depends on the environment in which the
fixture operates: damp, smoky or particularly dirty surroundings can require
cleaning fluid. Always dry the parts carefully.
6. Quick trouble shooting :
6.1 If the unit does not function – Check that the main power is on is in
working order
6.2 If the unit is not reacting to music – check the unit is in “sound to light”
mode and that the sensitivity control is fully clockwise.
6.3 If the product is not reacting to DMX signals, check the cables and
connections
User Manual – PB-1 Foldable PAR BAR 151.559UK
9
12. Rear display functions and meanings:
If you are not using the foot controller you can use the rear panel to select
different operational modes. The below table shows the meaning of each one;
Mode Sub
Menu
Function
ADDR A001 Set DMX address A001-A512
NAST Master Mode SLND
SLAL Slave Mode
CHND 4ch or
12ch
4 or 13 DMX mode
SH0-12 12 Different shows to choose from SHND
FADE speed( SP 1……SP 8)
COL0 - 9 Nine kinds of color
settings(COL1…….COL9)
R:0---255 Red Brightness
G: 0---255 Green Brightness
COLO
NANV
(Manual
Mode) B: 0---255 Blue Brightness
On LED Display On LED
Off LED Display Off
DISP Set display up or upside down
TEST Color testing mode
FHNS Fixture hours
