150.452UK User Manual
Panel Layout
1. IEC mains inlet and fuse holder
2. Power switch on/off
3. DMX Output
4. DMX Input
Control panel and display
ESC: Press ESC to return to menu function
UP: Increase one step each time.
DOWN: Decrease one step each time.
ENTER: Confirms the functions you select.
Display Function

DMX address

Reverse Pan movement on or off


Reverse Tilt movement on or off


Auto program 1

Auto program 2

Sound to light on

Sound to light off

Turns display off after 30 seconds

Leaves display on all the time

Resets the fixture
Specifications
Item Value
Power supply 110 - 240Vac, 50/60Hz
Power consumption 110W
Fuse rating F5A
LED type 1 x 60W White (8000k)
Beam angle 12°
Colour 7 + White
Gobos 6 + Spot
PAN Range 540°
Tilt Range 230°
DMX channels 12
Dimensions 260 x 260 x 350mm
Weight 8kg
Laser & LED safety standard BSEN60825-1 2007
