User Manual – QTFX-2000
160.457UK
8
11. Layout :
1)
Mounting Bracket
2)
5L Bottle slot
3)
Safety Loop
4)
Carry handle
5)
Smoke output
6)
Thumb screws
7)
Wireless remote system
User Manual – QTFX-2000
160.457UK
9
12. Rear Layout :
1)
Power ON/OFF
2)
IEC Power IN
3)
Timer Control (see next section)
4)
Rear carry handle
5)
DMX OUT
6)
DMX IN
7)
Wireless remote connection
8)
Set DMX address (see Section 14)
