151.602UK User Manual
Introduction
Thank you for choosing the QTX LED DUOBEAM quad colour dual LED barrel light as part of your effect
lighting rig. Please read these instructions in full to gain the best results from this item and avoid damage
through misuse.
Unpacking
Your LED DUOBEAM should reach you in good condition and be supplied with appropriate mains lead(s)
and mounting bracket. If there are any signs of damage or items missing from the packaging, contact
your dealer immediately.
Warning
To prevent risk of fire or electric shock, do not expose any components to rain or moisture.
If liquids are spilled on the housing, disconnect mains and allow unit to dry out & have checked by
qualified personnel before further use. Avoid any impact or extreme pressure to the housing.
No user serviceable parts inside – Do not open the case – refer all servicing to qualified service personnel.
Safety
 Check for correct voltage and condition of IEC lead before connecting to power outlet
 Ensure DMX leads are good condition with no short connections or damaged plugs
Placement
 Mount the unit to a lighting stand or ceiling using the adjustable bracket included
 If the unit is mounted at height, a drop cable should be attached for safety
 If free-standing, ensure that the unit is sited on a stable, non-slip surface.
 Ensure adequate access to controls and connections
Cleaning
 Use a soft dry or slightly damp to clean the cabinet. Do not use strong solvents for cleaning the unit
Setting up
Install the LED DUOBEAM so that the front panel is facing the area to be lighted.
Experiment with positioning to get the best coverage from the mirrored beams.
For DMX or master/slave control, link control signals with XLR leads from DMX out to DMX in connectors.
Connect mains using an appropriate IEC lead to the mains inlet.
Operation
The LED DUOBEAM can be operated in either DMX or standalone auto and sound activated modes.
For auto or sound-activated modes, you can select 1 unit to be master with XLR connection to a slave.
Select the mode to be used via the 4 button panel with digital display as shown below.
Display
Mode Function
 DMX512 Address setting A001 – A512
 Slave mode Receives control via XLR from another LED DUOBEAM
 Auto programme mode Auto run sequence to internal programme

 : sound activated mode 1 Sound-to-light with auto run when no sound present
 : sound activated mode 2 Sound-to-light with LEDs off when no sound present
