Establishing Power to Electronics
Once the two power input wires of the shielded cable are properly connected to the terminals inside the Ex
enclosure as described above, connect the other end of the two wires to a suitable 12-24 VDC power supply
such as a battery, PLC, DCS, etc.
The digital display responds instantaneously. When power is applied, the transmitter performs several self-
diagnostic system status checks termed as “START-UP TEST” as illustrated below:
START-UP TEST
ELECTRONICS – PASS
TEMP SENSOR – PASS
BAROMETRIC SENSOR – PASS
REV. 2.14
After self diagnostic tests, the analyzer turns itself into the sampling mode. And displays oxygen contents
the sensor is exposed to, the analysis range, the ambient temperature and pressure.
0.3 %
AUTO SAMPLING
0-1% RANGE
76 F 100 KPA
Menu Navigation
The four (4) pushbuttons located on the front of the transmitter control the micro-processor functions:
Blue ENTER (select)
Yellow UP ARROW
Yellow DOWN ARROW
Green MENU (escape)
