3 Safety Guidelines
General
This section summarizes the essential precautions applicable to the GPR-2900 Oxygen Analyzer. Additional precautions specific
to individual analyzer are contained in the following sections of this manual. To operate the analyzer safely and obtain
maximum performance follow the basic guidelines outlined in this Owner’s Manual.
Caution: This symbol is used throughout the Owner’s Manual to Caution and alert the user to recommended safety and/or
operating guidelines.
Danger: This symbol is used throughout the Owner’s Manual to identify sources of immediate Danger such as the presence of
hazardous voltages.
Read Instructions: Before operating the analyzer read the instructions.
Retain Instructions: The safety precautions and operating instructions found in the Owner’s Manual should be retained for
future reference.
Heed Warnings: Follow all warnings on the analyzer, accessories (if any) and in this Owner’s Manual.
Follow Instructions: Observe all precautions and operating instructions. Failure to do so may result in personal injury or
damage to the analyzer.
Pressure and Flow
Inlet Pressure: GPR-2900 Oxygen Analyzers is designed for flowing samples, equipped with 1/8” bulkhead tube fitting
connections on the side of the sensor flow housing (unless otherwise indicated, either fitting can serve as inlet or vent) and are
intended to operate at positive pressure regulated to between 5-30 psig.
Outlet Pressure: The sample gas vent pressure should be atmospheric.
Installation
Oxygen Sensor: DO NOT open the sensor. The sensor contains a corrosive liquid electrolyte that could be harmful if touched
or ingested, refer to the Material Safety Data Sheet contained in the Owner’s Manual appendix. Avoid contact with any liquid or
crystal type powder in or around the sensor or sensor housing, as either could be a form of electrolyte. Leaking sensors should
be disposed of in accordance with local regulations.
Mounting: The analyzer is approved for indoor use, outdoor use requires mounting in a secondary enclosure with the
appropriate NEMA rating. Mount as recommended by the manufacturer.
Power: Supply power to the analyzer only as rated by the specification or markings on the analyzer enclosure. The wiring that
connects the analyzer to the power source should be installed in accordance with recognized electrical standards and so they
are not pinched particularly near the power source and the point where they attach to the analyzer. Never yank wiring to
remove it from an outlet or from the analyzer.
Operating Temperature: The maximum operating temperature is 45º C.
Heat: Situate and store the analyzer away from sources of heat.
Liquid and Object Entry: The analyzer should not be immersed in any liquid. Care should be taken so that liquids are not
spilled into and objects do not fall into the inside of the analyzer.
Handling: Do not use force when using the switches and knobs. Before moving your analyzer be sure to disconnect the
wiring/power cord and any cables connected to the output terminals located on the analyzer.
