Air Suspension C-2293 REV 3 User Manual
Page 7
7
REV 3
06/06/2014
C-2293
C
-2293
ARNOTT high pERfORmANCE
COil spRiNg CONVERsiON kiT
fOR
2003-2006
liNCOlN NAVigATOR/fORD EXpEDiTiON
ELEctRoNIc BYPAss moDULE INstALLAtIoN
1.
locate tHe veHicles air sUspension control MoDUle UnDer tHe leFt siDe oF tHe DasH BoarD.
(FigUre a)
FigUre a
2.
start BY locating a sUitaBle groUnD For tHe electronic BYpass MoDUle anD secUre tHe
BlacK Wire. eXaMple: tHe MoUting BracKet For tHe control MoDUle. (FigUre B)
3.
locate pin# 26 (soliD pUrple Wire) on tHe BlacK plUg anD cUt leaving a sUitaBle lengtH
to WorK WitH. (FigUre c)
FigUre B
FigUre c
