ARNOTT high pERfORmANCE
COil spRiNg CONVERsiON kiT
fOR
2003-2006
liNCOlN NAVigATOR/fORD EXpEDiTiON
4.
loosen anD reMove tHe top tHree (3) MoUnting nUts anD tHe BottoM MoUnting nUt/Bolt. (FigUre 20-4)
5.
reMove tHe air strUt FroM veHicle. (FigUre 20-5)
FigUre 20-4
FigUre 20-5
6.
reMoval copMlete.
REAR coIL sPRING INstALLAtIoN
1.
install tHe coil spring asseBlY onto tHe veHicle in reverse orDer oF air strUt reMoval.
secUre tHe air Hose anD electrical connector in a sUitaBle location.
Tighten all nuts and bolts to manufacturer's specifications during the installation process.
