16. Air vents.
Air vents. These vents allow air ventilation.
DO NOT block the air vents on the chassis. Always provide proper ventilation for your
computer.
17. �GA port.
�GA port. This port is for VGA-compatible devices such as a VGA monitor.
2
4
BP6230/SD510
13
16
17
1
3
5
3
6
7 8
12
14
1.
PS/2 mouse port (green). This port is for a PS/2 mouse.
2.
PS/2 keyboard port (purple). This port is for a PS/2 keyboard.
3.
USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports connect to USB 2.0
devices such as a mouse, printer, scanner, camera, PDA, and others.
4.
D�I-D port.
D�I-D port. This port is for any DVI-D compatible device and is HDCP compliant
allowing playback of HD DVD, Blu-ray, and other protected content.
5.
USB 3.0 ports.
USB 3.0 ports. These Universal Serial Bus 3.0 (USB 3.0) ports connect to USB 3.0
devices such as a mouse, printer, scanner, camera, PDA, and others.
14
9 10 11
15
