ASUS A500/AS-D920, BA5190 2-41
Creating a RAID 5 set (parity)
To create a RAID 5 set:
1. From the utility main menu, select 1. Create RAID Volume and press
. The following screen appears.
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume? (Y/N):
7. Press to create the RAID volume and return to the main menu or to
go back to the Create Volume menu.
6. Press when the Create Volume item is highlighted. The following
warning message appears.
2. Enter a name for the RAID 5 set and press .
3. When the RAID Level item is highlighted, press the up/down arrow key to
select RAID 5(Parity), and then press .
Intel(R) Matrix Storage Manager option ROM v8.0.0.1027 ICH10R wRAID5
Copyright(C) 2003-08 Intel Corporation. All Rights Reserved.
[ CREATE VOLUME MENU ]
[ HELP ]
Enter a unique volume name that has no special characters and is
16 characters or less.
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [Enter]-Select
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Volume5
RAID5(Parity)
Select Disks
64KB
XXX GB
Create Volume
