4. Power connector.
5. One of the following audio ports configurations:
• 6-channel
• 8-channel
Refer to the configuration table in the User Guide
for details.
6. LAN (RJ-45) port ( )
7. USB 2.0 / USB 3.0 ports ( )
8. VGA port (
)
9. One of the following ports:
• E-SATA port ( )
• Serial (COM1) port ( )
• DVI port ( )
• HDMI port ( )
Do NOT cover the rear vent , and the ambient
temperature is limited up to 35 o C to prevent the
system from overheating.
Rear panel features
1
2
3
1. Chassis air vent.
2. Power supply unit fan vent.
3. Chassis fan vent.
4
5
9
