Asus WL-330N - Manual (Page 6)

6
NOTE: For more details on the operation modes, refer to the Operation
modes section.
English
B. Set the TCP/IP settings to automatically obtain an IP address.
1. Click the Apple icon
> System Preferences > Network.
2. Select Ethernet and select Using DHCP in the Configure field.
3. Click Apply when done.
Frequently Asked Questions
Q1: I cannot access the web GUI to configure the wireless router settings.
• Close all running web browsers and launch again.
• Follow the steps below to configure your computer settings based on its
operating system.
Windows 7
A. Disable the proxy server, if enabled.
1. Click Start > Internet Explorer to launch the web browser.
2. Click Tools > Internet options > Connections tab > LAN settings.
3. From the Local Area Network (LAN) Settings screen, untick Use a proxy
server for your LAN.
4. Click OK when done.
B. Set the TCP/IP settings to automatically obtain an IP address.
1. Click Start > Control Panel > Network and Internet > Network and Sharing
Center > Manage network connections.
2. Select Internet Protocol Version 4 (TCP/IPv4), then click Properties.
3. Tick Obtain an IP address automatically.
4. Click OK when done.
C. Disable the dial-up connection, if enabled.
1. Click Start > Internet Explorer to launch the browser.
2. Click Tools > Internet options > Connections tab.
3. Tick Never dial a connection.
4. Click OK when done.
Mac 10.5.8
A. Disable the proxy server, if enabled.
1. From the menu bar, click Safari > Preferences... > Advanced tab.
2. Click Change Settings... in the Proxies field.
3. From the list of protocols, deselect FTP Proxy and Web Proxy (HTTP).
4. Click OK when done.
