1.7 System memory
1.7.1 1.7.1 1.7.1 1.7.1 1.7.1 Overview Overview Overview Overview Overview
The motherboard comes with four 184-pin Double Data Rate (DDR) Dual
Inline Memory Modules (DIMM) sockets.
The following figure illustrates the location of the sockets:
1.7.2 1.7.2 1.7.2 1.7.2 1.7.2 Memory Configurations Memory Configurations Memory Configurations Memory Configurations Memory Configurations
You may install 128 MB, 256 MB, 512 MB and 1 GB unbuffered non-ECC
DDR DIMMs into the DIMM sockets using the memory configurations in this
section.
P5S800-VM
®
P5S800-VM 184-pin DDR DIMM sockets
DIMM1 DIMM2
Installing DDR DIMMs other than the recommended configurations may
cause memory sizing error or system boot failure. Use any of the
recommended configurations in Table 1.
