ASUS RS160-S5/PX4 1-3
1.3 System specifications
The ASUS RS160-S5/PX4 is a server featuring the ASUS DSEB-DG/SAS server
board. The server supports Intel ® LGA771 Xeon ® E5400 / E5300 / E5200 / E5100
Series processors with EM64T technology, plus other latest technologies through
the chipsets onboard.
Model Name RS160-E4/SI
Processor / System Bus
2 x Socket LGA771
Quad-Core Intel ® Xeon ® E5400 (45nm) / E5300
series processors
Dual-Core Intel ® Xeon ® E5200 (45nm) / 5100
series processors
FSB 1600 / 1333 / 1066 / 667 MHz EM64T
2 x 2M, 4M, 8M, and 12M L2 cache
Core Logic
Intel ® 5400 Memory Controller Hub (MCH)
Intel ® 6321ESB I/O Controller Hub (ICH)
ASUS Features Smart Fan
√
ASWM2.0 √
Memory
Total Slots 8 (4-Channel)
Capacity Maximum up to 32GB
Memory Type
Fully-Buffered DIMM DDR2 800 / 667 / 533
Registered, ECC
Memory Size 512MB, 1GB, 2GB and 4GB*
Expansion Slots
Total PCI/PCI-X/
PCI-E Slots
1
Slot Type 1 x PCIe x16 slot (Full-Height / Half-Length)
Additional Slot 1
1 x SO-DIMM socket for optional ASMB3-SOL
PLUS
Storage SAS Controller
LSI 1068 PCI-X 8-port SAS controller:
LSI ® Integrated RAID 0, 1, 1E support
HDD Bays
I = internal
A or S will be
hot-swappable
4 x Hot-swap SAS/SATA II HDD Bays
Networking LAN
Intel ® 6321 + Intel ® 82563EB Dual Port GbE
2 x Intel ® 82573 GbE
Graphic VGA XGI Z9s PCI Display Controller 32MB
Auxiliary Storage FDD / CD / DVD
1 x Slim-type Optical Device Bay
Options: No Device / DVD-ROM / DVD-RW
Onboard I/O
1 x External Serial Port
4 x RJ-45 ports
4 x USB 2.0 ports (Front x 2, Rear x 2)
1 x VGA port
1 x PS/2 keyboard port
1 x PS/2 mouse port
OS Support
Windows ® Server 2003 R2 Enterprise 32/64-bit
RedHat ® Enterprise Linux AS3.0 32/64-bit
RedHat ® Enterprise Linux AS4.0 32/64-bit
SuSE ® Linux Enterprise Server 9 32/64-bit
(Subject to change without any notice)
(continued on the next page)
