ASUS PIKE 2308 2-19
2.2.5 Viewing SAS topology Viewing SAS topology
1. From the Adapter Properties screen, select SAS Topology, then press .
You may press to display device properties, or to display more keys.
2. Information about the volume and its member-disks are then displayed.
Esc = Exit F1/Shift+1 = Help
Alt+D = Device Properties Alt+M = More Keys
LSI Corp Config Utility v7.05.01.00 (2010.02.09)
SAS Topology -- SAS2308
Device Identifier Device
PIKE 2308(04:00) Info
﹂ Controller Direct Attach Devices Controller
﹂ RAID1 VOL LSI Logical Volume 3000
Esc = Exit Menu F1/Shift+1 = Help
Enter = Select Item -/+/Enter = Change Item
LSI Corp Config Utility v7.05.01.00 (2010.02.09)
Adapter Properties -- SAS2308
Adapter PIKE 2308
PCI Slot 07
PCI Address(Bus/Dev) 04:00
MPT Firmware Revision 5.00.00.00-IR
SAS Address 500E0180:1280E000
NVDATA Version 05.02
Status Enabled
Boot Order 0
Boot Support [Enabled BIOS & OS]
RAID Properties
SAS Topology
Advanced Adapter Properties
LSI Corp Config Utility v7.05.01.00 (2010.02.09)
SAS Topology -- SAS2308
More keys for the SAS Topology display:
Alt+B = Select or deselect a device as the preferred boot device
Alt+A = Select or deselect a device as the alternate boot device
Enter = On a SAS Enclosure or Expander - Expand or Collapse Item
Enter = On a Disk Drive - Turn on the Locate LED (next key press turns off)
