3 ASUSXonarHDAV1�3DeluxeSlimQuickStartGuide
English
3. Hardware introduction
3.1 Xonar HDAV 1.3 Slim card layout
1
2
3
4 5
No Item Description
1 S/PDIF Out port CoaxialandopticalTOSLINKcombodigitaloutputport�
Connectstoanexternaldigitaldecoderordigitalspeaker
systems,HomeTheatersystems,AVreceiversforoutputting
digitalaudioincludingPCM,DolbyDigital,DTS,WMA-Pro,
etc�
2 HDMI In port (for DVI
signal input)
ConnectstotheDVIportofagraphicscardusingthe
bundledHDMI-to-DVIcableforDVIsignaltransmission,or
connectstotheHDMIOutportofanHDMIgraphicscard
usinganHDMIcable�
3 HDMI Out port ConnectstoadevicewithHDMIsupport�
4 Front panel audio
header
Connectoneendofthefrontpanelaudiocabletothefront
panelaudioheaderontheXonarHDAV1�3Slimcard,with
theotherendtothechassis-mountedfrontpanelaudioI/O
module�
5 Aux Input Header UsuallyconnectstotheAnalogAudiooutputofTVtunercard
orothersoundsourceinsideyourPCsystem�(Tomonitor
your TV tuner card’s audio from this Aux-In, you must enable
the “monitor” function for Aux-In in the Xonar HDAV Center ‘s
recordingmixer�)
