Asus Z8PE-D12 - Manual (Page 22)

ASUS Z8PE-D12 Series
Chapter summary
2
2.1 Before you proceed ..................................................................... 2-3
2.2 Motherboard overview ................................................................. 2-6
2.3 Central Processing Unit (CPU) ................................................. 2-11
2.4 System memory ......................................................................... 2-16
2.5 Expansion slots .......................................................................... 2-19
2.6 Jumpers ...................................................................................... 2-25
2.7 Connectors ................................................................................. 2-31
