xi
Z8PE-D12 Series specifications summary
Model Name Z8PE-D12X Z8PE-D12
Processor Support / System Bus 2 * socket 1366 2 * socket 1366
Quad-Core Intel ® Xeon ®
W5500 Series (130W)
Quad-Core Intel ® Xeon ®
X5500 Series (95W)
Quad-Core Intel ® Xeon ®
E5500 Series (80W)
Quad-Core Intel ® Xeon ®
L5500 Series (60W)
Quad-Core Intel ® Xeon ®
W5500 Series (130W)
Quad-Core Intel ® Xeon ®
X5500 Series (95W)
Quad-Core Intel ® Xeon ®
E5500 Series (80W)
Quad-Core Intel ® Xeon ®
L5500 Series (60W)
QPI 4.8 / 5.86 / 6.4 GT/s QPI 4.8 / 5.86 / 6.4 GT/s
Core Logic Intel 5520 I/O Hub
Intel ICH10R I/O Controller
NEC uPD720404 PCI-X
Bridge
Intel 5520 I/O Hub
Intel ICH10R I/O Controller
Form Factor SSI EEB, 12” x 13” SSI EEB, 12” x 13”
ASUS Features Smart Fan V V
Rack Ready
(Rack and
Pedestal dual
use)
V V
ASWM V V
Memory Total Slots 12 (3-channel per CPU, 6
DIMM per CPU)
12 (3-channel per CPU, 6
DIMM per CPU)
Capacity Maximum up to 96GB
(RDIMM)
Maximum up to 24GB
(UDIMM)
Maximum up to 96GB
(RDIMM)
Maximum up to 24GB
(UDIMM)
Memory Type DDR3 800/1066/1333 Reg
DIMM/ Unbuffered DIMM
with ECC/ non ECC
DDR3 800/1066/1333 Reg
DIMM/ Unbuffered DIMM
with ECC/ non ECC
Memory Size 1 GB, 2GB, 4GB, 8GB* 1 GB, 2GB, 4GB, 8GB*
