Z8PE-D12 Series specifications summary
Expansion Slots
(follow SSI
Loacation #)
Total PCI/PCI-X/
PCI-E Slots
6 4
Slot Loacation 1 1 * PCI-X 100/133 MHz -
Slot Loacation 2 1 * PCI-X 100/133 MHz -
Slot Loacation 3 1 * PCI-E x16 (Gen2 X8
Link)
1 * PCI-E x16 (Gen2 X8
Link)
Slot Loacation 4 1 * PCI-E x16 (Gen2 X8
Link)
1 * PCI-E x16 (Gen2 X8
Link)
Slot Loacation 5 1 * PCI-E x16 (Gen2 X8
Link)
1 * PCI-E x16 (Gen2 X8
Link)
Slot Loacation 6 1 * PCI-E x16 (Gen2 x16
Link)
(Auto switch to x8 Link if
slot 5 is occupied )
1 * PCI-E x16 (Gen2 x16
Link)
(Auto switch to x8 Link if
slot 5 is occupied )
Slot Loacation 7 1* MIO Slot for Audio card 1* MIO Slot for Audio card
Additional Slot
1
1* PIKE Slot for Stroage
expansion
1* PIKE Slot for Stroage
expansion
Storage IDE Controller IT8213F IT8213F
SATA Controller Intel ® ICH10R:
6 SATA2 300MB/s ports
Intel Matrix Storage (for
Windows only)
(Support software RAID 0,
1, 10 & 5)
LSI ® MegaRAID (for Linux/
Windows)
(Support software RAID 0,
1, 10)
Intel ® ICH10R:
6 SATA2 300MB/s ports
Intel Matrix Storage (for
Windows only)
(Support software RAID 0,
1, 10 & 5)
LSI ® MegaRAID (for Linux/
Windows)
(Support software RAID 0,
1, 10)
SAS Controller Optional:
ASUS PIKE 1064E 4-port
SAS RAID card
Asus PIKE 1068E 8-port
SAS RAID card
Asus PIKE 1078 8-port SAS
HW RAID card
Optional:
ASUS PIKE 1064E 4-port
SAS RAID card
Asus PIKE 1068E 8-port
SAS RAID card
Asus PIKE 1078 8-port SAS
HW RAID card
Networking LAN 2* Intel 82574L PCIE GbE
LAN
2* Intel 82574L PCIE GbE
LAN
Graphic VGA Aspeed AST2050 8MB Aspeed AST2050 8MB
