2. Swing the left edge of the
front panel inward, then
attach the front panel
assembly hooks to the chassis
until they snap in place.
Do not use too much force
when replacing the front panel
assembly.
3. Slide the cover to the direction of
the front panel until it fits in
place.
4. Replace the cover screws.
2.9.2 2.9.2 2.9.2 2.9.2 2.9.2 Replacing the system cover Replacing the system cover Replacing the system cover Replacing the system cover Replacing the system cover
To replace the metal chassis support:
2. Match and insert the hooks of the
cover to the elongated holes on
the side of the chassis. All eight
hooks (four hooks on both sides)
of the cover must properly fit the
designated holes.
1. Reinstall the metal chassis
support and the expansion card
lock.
