Asus Pundit-PE3 User Manual
Page 23

2 - 7
2 - 7
2 - 7
2 - 7
2 - 7
A S U S P u n d i t - P E 3
A S U S P u n d i t - P E 3
A S U S P u n d i t - P E 3
A S U S P u n d i t - P E 3
A S U S P u n d i t - P E 3
The CPU fits in only one correct orientation. DO NOT force the CPU into
the socket to prevent bending the connectors on the socket and
damaging the CPU!
6.
Close the load plate (A), then
push the load lever (B) until
it snaps into the retention
tab.
A
B
The motherboard supports Intel
®
Pentium
®
4 LGA775 processors with
Hyper-Threading Technology. Refer to the Appendix for more
information.
