4-2 Chapter 4: Motherboard info
Chapter 4
4.1.1 Layout contents
Onboard LEDs Page
1. Baseboard Management Controller LED (BMC_LED1) 4-3
2. CPU Warning LED (ERR_CPU1/2) 4-3
3. DIMM Warning LED (ERR_DIMMA1~H1) 4-4
4. CATT Error LED (CATTERR_LED1) 4-4
5. Q-Code LED (LED1) 4-5
Jumpers Page
1. Clear RTC RAM (CLRTC1) 4-8
2. VGA controller setting (3-pin VGA_SW1) 4-9
3. LAN controller setting (3-pin LAN_SW1/ LAN_SW2) 4-9
4. LSI MegaRAID or Intel RSTe selection jumper (3-pin RAID_SEL1) 4-10
5. ME firmware force recovery setting (3-pin ME_RCVR1) 4-10
6. DDR3 thermal event setting (3-pin DIMMTRIP1) 4-11
7. PMBus 1.2 PSU select jumper (3-pin SMART_PSU1) 4-11
Internal connectors Page
1. Serial ATA 6.0/3.0 Gb/s connectors
(7-pin SATA6G 1–2 [light blue]; 7-pin SATA3G 3–6 [black])
4-12
2. PSAS connectors (PIKE required) 4-12
3. Hard disk activity LED connector (4-pin HDLED1) 4-13
4. USB connectors (10-1 pin USB34, USB56; A-Type USB10) 4-13
5. Serial port connector (10-1 pin COM2) 4-14
6. Serial General Purpose Input/Output connectors (6-1 pin
SGPIO1, 8-1 pin PSGPIO 1/2)
4-15
7. TPM connector (20-1 pin TPM1) 4-16
8. Power Supply SMBus connector (5-pin PSUSMB1) 4-16
9. EATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1,
8-pin EATX12V2 )
4-17
10. CPU, front and rear fan connectors (4-pin CPU_FAN1-2,
FRNT_FAN1–4, REAR_FAN1-2)
4-18
11. System panel connector (20-1 pin PANEL1) 4-19
12. Auxiliary panel connector (20-2 pin AUX_PANEL1) 4-20
