5-30
Chapter 5: BIOS setup
Chapter 5
5.4.12 Onboard LAN Configuration
Launch INTEL W82574L OpROM
Onboard LAN Configuration
Intel LAN1 Enable
[Enabled]
Intel W82574L OpROM1
[PXE]
Intel LAN2 Enable
[Enabled]
Intel W82574L OpROM2
[PXE]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Intel LAN1 Enable [Enabled]
Enables or disables Intel LAN1 function.
Configuration options: [Disabled] [Enabled]
INTEL W82574L OpROM1 [PXE]
This item launched INTEL W82574L OpROM1.
Configuration options: [Disabled] [PXE] [iSCSI]
Intel LAN2 Enable [Enabled]
Enables or disables Intel LAN2 function.
Configuration options: [Disabled] [Enabled]
INTEL W82574L OpROM2 [PXE]
This item launched INTEL W82574L OpROM2.
Configuration options: [Disabled] [PXE] [iSCSI]
