Installation options – Asus TS700-X7/PS4 User Manual
Page 53
TS700-X7/PS4
3-1
Chapter 3
Installation options
3
3.1
Preparing the system for rack mounting
• The items required for the optional configurations described in this
chapter are not included in the standard barebone system package. These
items are purchased separately.
• We recommend that you allot at least 1U space above the server
system to ensure optimal thermal performance.
Removing the footpads
Refer to section 2.9.2 Chassis footpads for instructions on removing the
footpads.
Removing the top cover
Unscrew and slide the top cover toward
the rear panel, and then lift it up from
the chassis.
•
•
