ASUS RS100-E6/PI2 4-3
Layout contents
Jumpers Page
1. Clear RTC RAM (CLRTC1) 4-4
2. VGA controller setting (3-pin VGA_SW1) 4-5
3. CPU Fan and Chassis Fan control setting (3-pin CPUFAN_SEL1,
CHAFAN_SEL1)
4-5
4. LAN controller setting (3-pin LAN_SW1, LAN_SW2) 4-6
5. RAID configuration utility selection (3-pin RAID_SEL1) 4-6
6. Force BIOS recovery setting (3-pin RECOVERY1) 4-7
Internal connectors Page
1. Serial ATA connectors (7-pin SATA1–4 [Red], SATA5–6 [Black]) 4-8
2. Hard disk activity LED connector (4-pin HDLED1) 4-8
3. USB connector (10-1 pin USB34, USB56; A-Type USB7) 4-9
4. CPU, front and rear fan connectors (4-pin CPU_FAN1,
FRNT_FAN1, FRNT_FAN2, FRNT_FAN3, REAR_FAN1)
4-9
5. Serial General Purpose Input/Output connector (6-1 pin SGPIO1) 4-10
6. Serial port connector (10-1 pin COM2) 4-10
7. BMC header (BMC_FW1) 4-11
8. Power Supply SMBus connector (5-pin PSUSMB1) 4-11
9. ATX power connectors (24-pin ATXPWR1, 8-pin ATX12V1) 4-12
10. System panel connector (20-1 pin PANEL1) 4-13
11. Auxiliary panel connector (20-2 pin AUX_PANEL1) 4-14
