Slovensky, 1) káblové prepojenie – Asus WL-520GU User Manual
Page 97
Rýchly sprievodca pre spustenie bezdrôtového smerovača pre domácnosti so širokým rozsahomWL-520GU/GC
92
R
Slovensky
3. Pripojenie bezdrôtového smerovača ku
káblovému/DSL/satelitnému modemu
1) Káblové prepojenie
Poznámka: Používajte jedine adaptér, ktorý je súčasťou balenia. Používanie iných
adaptérov môže poškodiť zariadenie.
1
Modem
Wall Telephone Outlet
Wall Power Outlet
Phone
Power
2
Wall Power Outlet
ASUS Wireless Router
LAN
3
Modem
Wall Telephone Outlet
Wall Power Outlet
LAN
Power
Phone
Power
ASUS Wireless Router
WAN
Power
Nastavenie EZ
Resetovanie LAN
Napájanie
USB
WAN
Anténa
Rear Panel
