Ruuteri WL-520GU/GC Broad Range Wireless Family Router kiirjuhend
72
R
Eesti
3. Traadita ruuteri ühendamine kaabel/DSL/
satelliit-modemiga
1) Kaabli ühendamine
Märkus: *Kasutage ainult seadmega kaasnenud adapterit. Muude adapterite
kasutamine võib seadet kahjustada.
1
Modem
Wall Telephone Outlet
Wall Power Outlet
Phone
Power
2
Wall Power Outlet
ASUS Wireless Router
LAN
3
Modem
Wall Telephone Outlet
Wall Power Outlet
LAN
Power
Phone
Power
ASUS Wireless Router
WAN
Power
EZ Setup
Lähtestamine LAN
Toide
USB
WAN
Antenn
Tagapaneel
