4-20 Chapter 4: BIOS setup
4.4.8 Network Stack
Network Stack [Disable Link]
Enables or disables the network stack (Pxe and UEFI). Configuration options: [Disable Link]
[Enable]
4.5 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you to change
the fan settings.
4.5.1 CPU Temperature / MB Temperature [xxx�C/xxx�F] [xxx�C/xxx�F]
The onboard hardware monitor automatically detects and displays the CPU and motherboard
temperatures. Select Ignore if you do not wish to display the detected temperatures.
4.5.2 CPU / Chassis / [N/A]
The onboard hardware monitor automatically detects and displays the CPU and chassis fan
speeds in rotations per minute (RPM). If the fan is not connected to the motherboard, the field
shows N/A. Select Ignore if you do not wish to display the detected speed.
Main Advanced Monitor Boot Tool
CPU Temperature
EFI BIOS Utility - Advanced Mode
CPU Temperature +52ºC / +125ºF +52ºC / +125ºF
MB Temperature +38ºC / +100ºF
CPU Fan Speed 2129 RPM
Chassis Fan 1 Speed N/A
Chassis Fan 2 Speed N/A
Power Fan Speed N/A
CPU Q-Fan Control Enabled
Chassis Q-Fan Control Enabled
CPU Voltage +1.168 V
3.3V Voltage +3.296 V
5V Voltage +5.080 V
12V Voltage +12.096 V
Exit
