Chapter 1: Getting started

English

• The USB .0 ports only support Windows

7 or later versions. UASP standard only

supports Windows

• DO NOT connect a keyboard / mouse to any USB .0 port when installing Windows

operating system.

• Due to USB .0 controller limitation, USB .0 devices can only be used under Windows

OS environment and after the USB .0 driver installation.

• USB .0 devices can only be used as data storage only.
• We strongly recommend that you connect USB .0 devices to USB .0 ports for faster

and better performance for your USB .0 devices.

External SATA ports.

External SATA ports. These external SATA ports connects to SATA storage devices.

USB 3.0 ports, support ASUS USB 3.0 Boost UASP Mode. These Universal Serial

Bus .0 (USB .0) ports connect to USB .0 devices such as a mouse, printer,

scanner, camera, PDA, and others.

Side Speaker Out port (gray). This port connects to the side speakers in an 8-channel

audio configuration.

10. Rear Speaker Out port (black).

Rear Speaker Out port (black). This port connects to the rear speakers in a 4, 6, and

8-channel audio configuration.

11. Center/Subwoofer port (orange). This port connects to the center/subwoofer

speakers.

12. Microphone port (pink).

Microphone port (pink). This port connects to a microphone.

13. Line Out port (lime).

Line Out port (lime). This port connects to a headphone or speaker. In a 4, 6, or

8-channel configuration, the function of this port becomes Front Speaker Out.

14. Line In port (light blue).

Line In port (light blue). This port connects to a tape, CD, DVD player, or other audio

sources.

Refer to the audio configuration table below for the function of the audio ports in a 2, 4, 6,

or 8-channel configuration.

Audio 2, 4, 6, or 8-channel configuration

Port

Headset

2-channel

4-channel

6-channel

8-channel

Light Blue

Line In

Lime

Line Out

Front Speaker Out

Pink

Mic In

Orange

–

Center/Subwoofer

Black

–

Rear Speaker Out

Gray

–

Side Speaker Out
