2 - 1 8 2 - 1 8 2 - 1 8 2 - 1 8 2 - 1 8 C h a p t e r 2 : B I O S s e t u p C h a p t e r 2 : B I O S s e t u p C h a p t e r 2 : B I O S s e t u p C h a p t e r 2 : B I O S s e t u p C h a p t e r 2 : B I O S s e t u p
DRAM Configuration DRAM Configuration DRAM Configuration DRAM Configuration DRAM Configuration
The items in this sub-menu show the DRAM-related information that the
BIOS auto-detects.
DRAM Configuration
Timing Mode [Auto]
x Memclock index value (Mhz) 200Mhz
x CAS# Latency (Tcl) 2.5
x Min RAS# active time (Tras) 8T
x RAS# to CAS# delay (Trcd) 4T
x Row precharge time (Trp) 2T
x 1/T/2T Memory Timing 2T
Bottom of 32-bit [31:24] IO [E0]
DRAM Over 4G Remapping [Disabled]
MTRR mapping mode [Continuous]
Select Menu
Item Specific Help
to select DRAM
configuration. [Auto]
is recommended.
[Manual] allows you to
set each configuration
on your own.
2.4.2 2.4.2 2.4.2 2.4.2 2.4.2 Chipset configuration Chipset configuration Chipset configuration Chipset configuration Chipset configuration
The items in this menu show the chipset configuration settings. Select an
item then press to display a pop-up menu with the configuration
options.
Chipset
DRAM Configuration [Press Enter]
Errata 94 Enhanced [Enabled]
Select Menu
Item Specific Help
DRAM timing and
control.
