2-1 ASUS BP5120
2.1 Removing the covers
2.1.1 Removing the system cover
The system panel is secured with four screws on the rear panel. Before you
remove it, place the system horizontally.
To remove the system panel:
1. On the rear panel, locate the four screws that secure the cover to the
chassis. Use a Philips screw driver to remove the screws and keep them for
later use.
2. Slightly push the cover toward the rear panel until the side tabs are
disengaged from the chassis.
3. Lift the cover, then set aside.
1 1 1
2
3
1
