GigaX Series L2 Managed Switch User’s Guide
42
4.5.4 Static Multicast
This page can add multicast addresses into the multicast table. The switch can
hold up to 256 multicast entries. All the ports in the group will forward the
specified multicast packets to other ports in the group.
Show Group: selects “Add a new Group” to enter a new entry. Or select
an existing group address to display
MAC Address: selects the multicast address
VLAN: selects the vlan group
Click to make the setting effective. Click to refresh the
settings to current value.
Figure 20. Static Multicast
