Chapter 4, Customizing the fan settings – Asus Z87-WS User Manual
Page 143
ASUS Z87-WS
4-13
Chapter 4
Customizing the fan settings
Smart Mode
Smart Mode allows you to customize the fans’ rotation speeds and responsiveness based on
your system’s temperature.
Click to switch between
CPU and chassis fan
screens
Click to apply
changes
Click to undo
changes
Click to go
back to the
previous
screen
Click and drag
to set the fan’s
rotation speed
