Asus CG8480 - Manual (Page 16)

14 Chapter 1: Getting started
EN
GL
IS
H
EN
GL
IS
H
EN
GL
IS
H
EN
GL
IS
H
Refer to the audio configuration table below for the function of the audio ports in a 2, 4, 6,
or 8-channel configuration.
Audio 2, 4, 6, or 8-channel configuration
Port
Headset.
2-channel
4-channel 6-channel 8-channel
Light Blue Line In Line In Line In Line In
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out
Gray – – – Side Speaker Out
3.. DisplayPort. This port connects a display monitor or a home-theater system.
4.. DVI-D.port. This port is for any DVI-D compatible device and is HDCP compliant
allowing playback of HD DVD, Blu-ray, and other protected content.
5.. USB.3.0.ports.support.ASUS.USB.3.0.Boost.UASP.Mode..Bottom.port.supports.
USB.BIOS.Flashback.
6.. Side.Speaker.Out.port.(gray). This port connects to the side speakers in an 8-channel
audio configuration.
7.. Rear Speaker Out port (black). Rear.Speaker.Out.port.(black). This port connects to the rear speakers in a 4, 6, and
8-channel audio configuration.
8.. Center/Subwoofer.port.(orange). This port connects to the center/subwoofer
speakers.
9.. Microphone port (pink). Microphone.port.(pink). This port connects to a microphone.
10.. Line Out port (lime). Line.Out.port.(lime). This port connects to a headphone or speaker. In a 4, 6, or 8-
channel configuration, the function of this port becomes Front Speaker Out.
11.. Line In port (light blue). Line.In.port.(light.blue). This port connects to a tape, CD, DVD player, or other audio
sources.
12.. Air.vents. These vents allow air ventilation.
