ASUS Z9PH-D16 Series 4-19
Support for PCH Compatibility
Revision ID(CRID)
functionality.
Name Patsburg
Stepping 04 (B0 Stepping)
SB Chipset Configuration
PCH Compatibility RID [Disabled]
Deep Sx [Disabled]
SCU devices [Enabled]
Onboard SATA RAID Oprom [Enabled]
High Precision Event Timer Configuration
High Precision Timer [Enabled]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
PCH Configuration
PCH Compatibility RID [Disabled]
Support for PCH compatibility. Configuration options: [Disabled] [Enabled]
Deep Sx [Disabled]
Configuration options: [Disabled] [Enabled in S5] [Enabled in S4 and S5]
SCU devices [Enabled]
Allows you to enable or disable Patsburg SCU devices.
Configuration options: [Enabled] [Disabled]
Onboard SATA RAID Oprom [Enabled]
Allows you to enable or disable onboard SATA RAID option rom if Launch Storage
Oprom is enabled. Configuration options: [Disabled] [Enabled]
High Precision Event Timer Configuration
High Precision Timer [Enabled]
Allows you to enable or disable High Precision Event Timer.
Configuration options: [Disabled] [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
