Asus Z9PH-D16 User Manual
Page 26
2-8
Chapter 2: Hardware information
Internal connectors
Page
1.
Serial ATA connectors
(7-pin SATA1-2 [Lght blue], SATA3–4 [Black])
2-27
2.
ISAS connectors (7-pin ISAS1–4 [Gray])
2-27
3.
USB connector (5-1 pin USB3; A-Type USB4)
2-28
4.
Front fan connectors
(4-pin FRNT_FAN1, FRNT_FAN2, FRNT_FAN3, FRNT_FAN4)
2-28
5.
Serial General Purpose Input/Output connector
(6-1 pin SGPIO1)
2-29
6.
Serial General Purpose Input/Output connector
(8-1 pin ISGPIO1)
2-29
7.
ASMB6 header (ASMB6)
2-30
8.
Thermal sensor cable connectors (3-pin TR1, TR2)
2-31
9.
TPM connector (20-1 pin TPM1)
2-31
10.
Power Supply SMBus connector (6-1 pin PSUSMB1)
2-32
11.
Proprietary power connectors
(20-pin PWR1, 20-pin PWR2, 4-pin PWR3)
2-33
12.
System panel connector (20-pin PANEL1 [White])
2-34
13.
Auxiliary panel connector (20-pin AUX_PANEL1 [Black])
2-35
Internal LEDs
Page
1.
CPU WARNING LED (ERR_CPU1, ERR_CPU 2)
2-34
2.
BMC LED (BMC_LED1)
2-34
