ASUS Z9PH-D16 Series 4-15
QPI Configuration
Memory Configuration
CPU II0 Bridge Configuration
PCH Configuration
Intel(R) VT for Directed I/O Configuration
4.4.3 Chipset Configuration
QPI Configuration
Current QPI Link Speed Slow
Current QPI Link Freq 8.0 GT/s
Isoc [Enabled]
QPI Link Speed Mode [Fast]
QPI Link Frequency Select [Auto]
QPI Link0s [Disabled]
QPI Link0p [Disabled]
QPI Link1 [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
QPI Configuration Page
Enable or disable Isoc
Isoc [Enabled]
Configuration options: [Disabled] [Enabled]
QPI Link Speed Mode [Fast]
This item allows you to select the QPI link speed as either the fast mode or slow mode.
Configuration options: [Slow] [Fast]
Factory long duration power limit 115 Watts
Long duration power limit 0
Allows you to set long duration power limit in watts. Use the <+> and <-> keys to
adjust the value.
Factory long duration maintained 1000 ms
Long duration maintained 0
Allows you to set time window which the long duration power is maintained. Use
the <+> and <-> keys to adjust the value.
Recommended short duration power limitation 1.2 * Long Duration
Short duration power limit 0
Allows you to set short duration power limit in watts. Use the <+> and <-> keys to
adjust the value.
