14 RT-N1 B1 Chapter : Setting up the hardware
Setting up the wireless router in Repeater mode
In the Repeater mode, the wireless router extends your wireless network coverage
and provides you with higher quality wireless radio signals. The NAT, firewall, and
IP sharing services are disabled.
To set up the wireless router in Repeater mode:
1. Choose the Repeater mode.
RT-N12 B1
LAN1 LAN2 LAN3 LAN4 Internet Router AP
Repeater
. Connect your devices.
LAN1 LAN2 LAN3 LAN4 Internet
RT-N12 B1
Client
Modem
Wireless Router
Note: We recommend that you use an Ethernet cable (wired connection) to connect your
computer to the wireless router for initial configuration to avoid possible setup problems due to
wireless uncertainty.
