3. GigaX1005N/1008N technical specifications
Standard
IEEE802.3 10BASE-T Ethernet
IEEE802.3u 100BASE-TX Fast Ethernet
IEEE 802.3x Flow Control and Back-pressure
Protocol
CSMA/CD
Connector
5/8 x 10/100BaseTX RJ-45 ports with Auto MDI/MDIX
Forwarding Rate 14,880 pps per Ethernet port
148,800 pps per Fast Ethernet port
MAC address
GigaX1005N: 1k; GigaX1008N: 1k
Memory Buffer
GigaX1005N:1Mb; GigaX1008N: 768kb
LED
Per port: Link/ Activity; Per unit: Power
Network Cable
10BASE-T: 2-pair UTP/STP Cat. 3,4,5 cable (100m)
EIA/TIA-568 100-ohm STP (100m)
100BASE-TX: 2-pair UTP/STP Cat. 5 cable (100m)
EIA/TIA-568 100-ohm (100m)
Dimension
165mm x 100mm x 32.5mm (W x D x H)
Power
Consumption
GigaX1005N: 4.3Watts max.
GigaX1008N: 4.5Watts max.
Operation
Environment
0˚C to 45˚C (32˚F to 113˚F)
10% to 90% humidity (Non-condensing)
Power Supply
AC 100-240V, 50~60Hz
EMI & Safety
FCC Class B, CE, UL
